Tricorder Tech: High-speed, Auto-polarization Modulated 3D Structured Illumination Microscopy Imaging

By Keith Cowing
Press Release
February 16, 2024
Filed under , , , , ,
Tricorder Tech: High-speed, Auto-polarization Modulated 3D Structured Illumination Microscopy Imaging
Open-source core technology embedded inside projector hardware enables high-speed, auto-polarization modulated 3D structured illumination microscopy (SIM) imaging. 3DSIM reconstruction of plant and animal tissue samples: (a) cell walls in oleander leaves, (b) hollow structures within black algal leaves, (c) root tips of corn tassels, and (d) actin filaments in mouse kidney tissue; corresponding maximum intensity projection (MIP) images are shown respectively in the bottom row (e-h). Scale bar: 2 μm. CREDIT Li, Cao, et al., doi 10.1117/1.APN.3.1.016001.

Editor’s note: When we send Away Teams on Astrobiology and Astrogeology expeditions to other worlds they are going to need to be rather self-contained. Indeed the bulk of their preliminary research may well be done off world. Having the best, most compact tools is of paramount importance. This goes for tricorders to be used on field trips and equipment to be used back at Base Camp. The technology – open source technology – described here is a promising example of what we may be able to equip future explorers with.

In the ever-evolving realm of microscopy, recent years have witnessed remarkable strides in both hardware and algorithms, propelling our ability to explore the infinitesimal wonders of life. However, the journey towards three-dimensional structured illumination microscopy (3DSIM) has been hampered by challenges arising from the speed and intricacy of polarization modulation.

Introducing the DMD-3DSIM System

Enter the high-speed modulation 3DSIM system “DMD-3DSIM,” combining digital display with super-resolution imaging, allowing scientists to see cellular structures in unprecedented detail. As reported in Advanced Photonics Nexus, Professor Peng Xi’s team at Peking University developed this innovative setup around a digital micromirror device (DMD) and an electro-optic modulator (EOM). It tackles resolution challenges by significantly improving both lateral (side-to-side) and axial (top-to-bottom) resolution, for a 3D spatial resolution reportedly twice that achieved by traditional wide-field imaging techniques.

Polarized insight into cellular structures

In practical terms, this means DMD-3DSIM can capture intricate details of subcellular structures, such as the nuclear pore complex, microtubules, actin filaments, and mitochondria in animal cells. The system’s application was extended to study highly scattering plant cell ultrastructures, such as cell walls in oleander leaves and hollow structures in black algal leaves. Even in a mouse kidney slice, the system revealed a pronounced polarization effect in actin filaments.

An open gateway to discovery

What makes DMD-3DSIM even more exciting is a commitment to open science. Xi’s team has made all the hardware components and control mechanisms openly available on Github, fostering collaboration and encouraging the scientific community to build upon this technology.

The DMD-3DSIM technique not only facilitates significant biological discoveries but also lays the groundwork for the next generation of 3DSIM. In applications involving live cell imaging, advancements in brighter and more photostable dyes, denoising algorithms, and deep learning models based on neural networks promise to enhance imaging duration, information retrieval, and real-time restoration of 3DSIM images from noisy data. By combining hardware and software openness, the researchers hope to pave the way for the future of multidimensional imaging.

For more details, read the original Gold Open Access article by Y. Li, R. Cao, et al., “High-speed autopolarization synchronization modulation three-dimensional structured illumination microscopy,” Adv. Photon. Nexus 3(1) 016001 (2023), doi 10.1117/1.APN.3.1.016001.
